Supported Upgradable Version: 8.7.3
Release Highlights
Modeled Only: Hangers
Hangers set to "Modeled Only" are not visible in the Layout and Output Material Lists.
Modeled Only: Supporting Flush Beams
Flush beams with members hanging off of them, set to "Modeled Only" affect the beams only, and not the attached hangers.
Group Label: Visibility
- Grouped labels respect the visibility switch when assigned to a layer.
- Grouped Hanger Labels are visible on the same level as the supported member when the supporting member is on a sperate level.
Ledgers on 8" Walls
Ledgers associate correctly to walls thicker than 8".
DXF/DWG Trace Object Line Styles
Changing DXF/DWG Trace Object Line Styles in Program Settings from Use Source File to Use Program Settings saves as expected.
PDF: Cropped Layer/Visibility
Cropping a PDF after import maintains the associated layer(s) and visibility.
Options: Design Stability and Lot-specific Export
Updates to the existing Option Manager, adding Design Stability and relocating related workflow capabilities, allowing members to retain their design status, labels, groupings, and annotations across elevations and options while enabling users to create production-ready lot-specific files from reusable combos.
